Unidrive "M100" & "M101" AC Open Loop Drives

****Currently Obsolete by the manufacturer. A replacement Drive is available.

**Legacy Product Replaced by Commander C200

Please contact Microcon for a Replacement****

Unidrive M100 AC drive - Value drive with quality and performance for open loop applications

0.33hp - 10hp (0.25kW - 7.5kW)

115V / 230V / 460V

M100 delivers an economical open loop drive for general Manufacturing Automation applications, with Control Techniques’ proven quality and class leading motor operation.

Availability Note: Please see the frame size/dimension table under the Specifications tab below for availability of specific frame sizes. Frame sizes marked with an asterisk indicate future availability.

Features

Quick and easy to install and configure

  • Simple and easy to read high brightness LED keypad as standard

  • No unnecessary features

  • 10 most commonly used parameters on front of drive

Reduce machine size and cost

  • Compact drive dimensions, among the smallest in class at every power rating

Save energy

  • Low losses up to 98% efficient

  • Low power standby mode

Robust design for manufacturing environments

  • Conformal coating supported through extensive environmental testing and certification

Typical applications

  • Frequency control for conveyors, fans, pumps and mixers

Specifications

Key data

  • Heavy Duty rating: 0.33hp - 10hp (0.25kW - 7.5kW)

  • Supply phases: Size 1 to 4: 110V drives – 1 phase, 230 and 400 V drives - 1 or 3 phase

Standard features

Keypad:

  • M100: Fixed LED

  • M101: Fixed LED with speed reference potentiometer

Parameter cloning via:

  • SD card

Voltage ratings

115V (100V - 120V ± 10%)

X

230V (200V - 240V ± 10%)

X

460V (380V - 480V ± 10%)

X

575V (500V - 575V ± 10%)

690V (500V - 690V ± 10%)



Control mode

Open loop vector or V/Hz induction motor control

X

Open loop Rotor Flux Control for induction motors (RFC-A)



Open loop permanent magnet motor control (RFC-S)



Closed loop Rotor Flux Control for induction motors (RFC-A)



Closed loop permanent magnet motor control (RFC-S)



Active Front End (AFE) power quality convertor



   frame size

 Dimensions (H x W x D)


 mm

 in

1

  139 x 75 x 130  5.5 x 3.0 x 5.1

2

  180 x 75 x 150  7.1 x 3.0 x 5.9

3

  200 x 90 x 160  7.9 x 3.5 x 6.3

4

 245 x 115 x 175 9.7 x 4.5 x 6.9

Options

Drive variant

M101 variant
Provides a speed reference potentiometer keypad to enhance customer choice and ease of use



Drive interface units - Back-up



AI-Back-up Adaptor
Port adaptor that allows the drive to use an SD card for parameter cloning, and an input for 24 V back-up





Unidrive M100 Available Sizes

115 VAC, Single Phase 50/60 Hz Input, 230 VAC 3-phase Output

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M100-01100017 6.3 X 3.0 X 5.1 1.7
0.5 2.4 0.5 2.4 M100-01100024
1 4.2 1 4.2 M100-02100042 8.1 X 3.0 X 5.9 2.2
1.5 5.6 1.5 5.6 M100-02100056



230 VAC, Single Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M100-01200017 6.3 X 3.0 5.1 1.7
0.5 2.4 0.5 2.4 M100-01200024
0.75 3.3 0.75 3.3 M100-01200033
1 4.2 1 4.2 M100-01200042
0.5 2.4 0.5 2.4 M100-02200024 8.1 X 3.0 X 5.9 2.2
0.75 3.3 0.75 3.3 M100-02200033
1 4.2 1 4.2 M100-02200042
1.5 5.6 1.5 5.6 M100-02200056
2 7.5 2 7.5 M100-02200075
3 10 3 10 M100-03200100 8.9 X 3.5 X 6.3 3.3
3 13.3 3 13.3 M100-04200133 10.9 X 4.5 X 6.9 6.9



230 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 2.4 0.5 2.4 M100-02200024 8.1 X 3.1 X 5.9 2.2
0.75 3.3 0.75 3.3 M100-02200033
1 4.2 1 4.2 M100-02200042
1.5 5.6 1.5 5.6 M100-02200056
2 7.5 2 7.5 M100-02200075
3 10 3 10 M100-03200100 8.9 x 3.5 x 6.3 3.3
3 13.3 3 13.3 M100-04200133

10.9 X 4.5 X 6.9

 6.9
5 17.6 5 17.6 M100-04200176



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 1.3 0.5 1.3 M100-02400013 8.1 x 3.1 x 5.9 2.2
0.75 1.8 0.75 1.8 M100-02400018
1 2.3 1 2.3 M100-02400023
1.5 3.2 1.5 3.2 M100-02400032
2 4.1 2 4.1 M100-02400041
3 5.6 3 5.6 M100-03400056 8.9 x 3.5 x 6.3 3.3
3 7.3 3 7.3 M100-03400073
5 9.4 5 9.4 M100-03400094
7.5 13.5 7.5 13.5 M100-04400135 10.9 x 4.5 x 6.9 6.9
10 17 10 17 M100-04400170

***Keypads are sold separate.

Unidrive M101 Available Sizes

115 VAC, Single Phase 50/60 Hz Input, 230 VAC 3-phase Output

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M101-01100017 6.3 x 3.0 x 5.6 1.7
0.5 2.4 0.5 2.4 M101-01100024
1 4.2 1 4.2 M101-02100042 8.1 x 3.1 x 6.3 2.2
1.5 5.6 1.5 5.6 M101-02100056



230 VAC, Single Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M101-01200017 6.3 x 3.0 x 5.6 1.7
0.5 2.4 0.5 2.4 M101-01200024
0.75 3.3 0.75 3.3 M101-01200033
1 4.2 1 4.2 M101-01200042
0.5 2.4 0.5 2.4 M101-02200024 8.1 x 3.1 x 6.3 2.2
0.75 3.3 0.75 3.3 M101-02200033
1 4.2 1 4.2 M101-02200042
1.5 5.6 1.5 5.6 M101-02200056
2 7.5 2 7.5 M101-02200075
3 10 3 10 M101-03200100 8.9 x 3.5 x 6.7 3.3
3 13.3 3 13.3 M101-04200133 10.9 x 4.5 x 7.3 6.9



230 VAC, 3- Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 2.4 0.5 2.4 M101-02200024 8.1 x 3.1 x 6.3 2.2
0.75 3.3 0.75 3.3 M101-02200033
1 4.2 1 4.2 M101-02200042
1.5 5.6 1.5 5.6 M101-02200056
2 7.5 2 7.5 M101-02200075
3 10 3 10 M101-03200100 8.9 x 3.5 x 6.7 3.3
3 13.3 3 13.3 M101-04200133 10.9 x 4.5 x 7.3 6.9
5 17.6 5 17.6 M101-04200176



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 1.3 0.5 1.3 M101-02400013 8.1 x 3.1 x 6.3 2.2
0.75 1.8 0.75 1.8 M101-02400018
1 2.3 1 2.3 M101-024-00023
1.5 3.2 1.5 3.2 M101-02400032
2 4.1 2 4.1 M101-02400041
3 5.6 3 5.6 M101-03400056 8.9 x 3.5 x 6.7 3.3
3 7.3 3 7.3 M101-03400073
5 9.4 5 9.4 M101-03400094
7.5 13.5 7.5 13.5 M101-04400135 10.9 x 4.5 x 7.3 6.9
10 17 10 17 M101-04400170
