TORQUEMASTER™ 3500 SERIES
Brushless Servo Motors

Series 3500, is a high performance, permanent magnet brush servo motor for use in various industrial direct drive or geared servo systems
  • Rugged industrial construction
  • Continuous torque ratings up to 11 lb-in --with speeds up to 4600 RPM (no load)
  • Peak torque ratings up to 94 lb-in
  • IP65 Sealing available
  • High torque-to-inertia ratio delivers maximum torque per frame size
  • Superior low speed performance
  • Numerous custom options available
    •
      Performance Benefits
    Cleveland Motion Controls specializes in the design of high performance brush servo motors that provide efficiency, flexibility of application, and a long and trouble-free service life. Our TORQUEMASTER™ 3500 series is no exception. With fast response, accurate control and high torque-to-inertia ratios, you can count on the TORQUEMASTER 3500 Series of brush servo motors to provide smooth operation throughout a full speed range.    		   The 3500 Series delivers smooth and superior low speed performance, and maximum power ratings with low thermal resistance for high speed performance. In addition, with maximum torque in a smaller package, you can count on better pricing for a better overall value. When integrated with high performance brush amplifiers, TORQUEMASTER 3500 Series brush servo motors provide effective and highly efficient motion control solutions for a wide range of applications --including factory automation, packaging, robotics, machine tools, medical instrumentation and more.
    Design Features
    TORQUEMASTER 3500 Series brush servo motors are rated from 4.3 lb-in to 11 lb-in with speeds and torque stability up to 4600 RPM. They utilize the latest in high performance permanent magnet technology, and are available in eight standard windings to meet your most demanding applications.    		   Each brush servo motor in the TORQUEMASTER 3500 Series is ruggedly designed and manufactured for reliable performance. Motors can be customized to fit your exact application with tachometers, encoders, brakes and other options.
