TORQUEMASTER™ 2100
SERIES
Brushless
Servo Motors
| Series
2100, is a high performance, permanent magnet brush servo motor for use
in various industrial direct drive or geared servo systems |
- Rugged industrial
construction
- Continuous torque ratings up
to 53 oz-in --with speeds up to 6500 RPM (no load)
- Peak torque ratings up to 300
oz-in
|
High torque-to-inertia ratio
delivers maximum torque per frame size
Superior low speed
performance
Numerous custom options
available
|
 |
|
Performance
Benefits
Cleveland Motion Controls
specializes in the design of high performance brush servo motors that
provide efficiency, flexibility of application, and a long and
trouble-free service life. Our TORQUEMASTER™
2100 series is no
exception. With fast response, accurate control and high
torque-to-inertia ratios, you can count on the TORQUEMASTER
2100 Series of brush
servomotors to provide smooth operation throughout a full speed range. |
|
The 2100
Series delivers smooth and
superior low speed performance, and maximum power ratings with low
thermal resistance for high-speed performance. In addition, with maximum
torque in a smaller package, you can count on better pricing for a
better overall value. When integrated with high performance brush
amplifiers, TORQUEMASTER
2100 Series brush servo
motors provide effective and highly efficient motion control solutions
for a wide range of applications --including factory automation,
packaging, robotics, machine tools, medical instrumentation and more. |
| |
|
|
Design Features
TORQUEMASTER
2100 Series brush servo
motors are rated from 18 oz-in to 53 oz-in with speeds and torque
stability up to 6500 RPM. They utilize the latest in high performance
permanent magnet technology, and are available in eight standard
windings (as well as custom windings) to meet your most demanding
applications. |
|
Each brush servo motor in the TORQUEMASTER
2100 Series is ruggedly
designed and manufactured for reliable performance. Motors can be
customized to fit your exact application with tachometers, encoders,
brakes and other options. |
|
